Product Name:Pilot-rc Elster Jet: FC1 3D – 2.2m
Product Code:FC1 3D – 2.2m
Price:RM 0.00
Availability:Yes

Product description:

FEATURES:

  • German design, by Ralph and Enrico from Elster Jet
  • Extremely lightweight full composite construction especially designed for outstanding 3D performance
  • Painted outside the mold so no seam lines
  • Ultra strong and light weight landing gear mounts, with factory installed blind nuts so mounting is just plug and play
  • Specially designed easy access to turbine for speedy installation
  • Field setup can be done in seconds, thanks to the quick releases on the wings without the need for any tools, and the single elevator bolt accessed from the side
  • Removable wing and elevator for easy transport

Please note that the FC1 is designed specifically for aerobatics and 3D vectored flight, with light weight being key. It is not designed to be used as a full power, high speed race plane.

INCLUDED HARDWARE:

  • Complete air frame (including carbon wing-tubes and preinstalled and painted fibreglass control horns)
  • Servo extension leads
  • Vector thrust pipe
  • 3.600ml fuel tank (optional upgrade to fuel bag)
  • 250ml UAT tank
  • Pre-prepared pushrods with ball links

Also available: Full retract combo.  Includes Pilot-RC electric retracts and electric brakes, specific for this model.

Also available: Turbine Ready version.  Includes all the above, plus x10 Pilot-RC servos, all pre-installed.  Just add your own turbine of choice.

REQUIRED HARDWARE:

Turbine size:

  • 80-140N  for normal sport flying
  • 160-180N for 3D vector flight – Avoid high speed, high G flying

Servos: Total x10 (x5 standard size + x5 medium size)

x3 standard size high torque
x2 for flaps (minimum 40kg)
x1 for rudder (minimum 40kg)

x7 medium size servo for steering (size: 35x15x30mm)
x2 for ailerons (minimum 16kg)
x2 for elevators (minimum 16kg)
x1 for vector elevator (minimum 16kg)
x1 for vector rudder (minimum 16kg)
x1 for steering (minimum 10kg)

Also requires all the usual accessories such as transmitter, receiver, batteries, powerbox and possibly other small accessories.

PILOT-RC RECOMMENDED HARDWARE:

  • Servos: Pilot-Rc PW48AH for flaps and rudder
  • Servos: Pilot-Rc PW16AH for ailerons, elevators and vector
  • Servos: Pilot-Rc PW10AH for steering
  • Servo arms: Pilot-Rc 1.6″, 1,2″ and 0,8″ Aluminium arms (included with Pilot-Rc servos)

PILOT-RC RECOMMENDED ACCESSORIES:

  • Pilot-RC Wingbags (2.2m FC1)
  • Pilot-RC Fuselage bag (2.2m FC1)




FC1 3D – 2.2m-Pilot-rc Elster Jet: FC1 3D – 2.2m
Price: RM 0.00
